Honeywell BW™ Clip4
Wearable, easy multi-gas detection that’s always on.
No charging, no battery or sensor replacements, no hassle. Simpler, low cost of ownership guaranteed by the Honeywell commitment to quality, and backed by a full ecosystem of supporting technologies.
When you clip on the Honeywell BW™ Clip4 you know it’s on
DATA SHEET DOWNLOAD
No charging, no battery or sensor replacements, no hassle. Simpler, low cost of ownership guaranteed by the Honeywell commitment to quality, and backed by a full ecosystem of supporting technologies.
When you clip on the Honeywell BW™ Clip4 you know it’s on
FEATURES AND BENEFITS
- 01. User-friendly tamper-proof operation with just one button
- 02. Daily full function self-test of sensors, battery status, circuit integrity, and audible/visual alarms
- 03. Tested for drops, collisions, waterproofing and dustproofing
- 04. Real-time gas concentrations shown on LCD
SPECIFICATION
| Classification criteria | classification | |
|---|---|---|
| Dimensions | 12.0 x 6.8 x 3.2 cm / 4.7 x 2.7 x 1.3 in. | |
| Weight | 233 g / 8.2 oz. | |
| Temperature | -20 ~ 50°C / -4 ~ 131°F | |
| Humidity | 5 ~ 95% RH (non-condensing) continuous | |
| Ingress Protection Rating | IP 68 | |
| Alarms | Visual, vibrating, audible (95 dB); Low, High, TWA, STEL, OL | |
| Self-Test | Activated detectors automatically perform one internal diagnostic test every 24 hours (sensors, battery, and circuitry). | |
| Battery Life | Two years, continous operation | |
| User options |
• Adjust STEL period (5-15 minutes in 1 minute intervals) • Calibration span levels • Calibration interval • Bump test interval • Select combustible gases measurement: 0-100% LEL Methane gas 0-5.0% v/v • Calibration due date (1 to 365 days, or set to zero for off) • Individual sensor enable/disable • Latching alarms • Stealth mode |
|
| Certifications |  |
Class I, Div 1, Group A, B, C, D Class I, Zone 0, Group IIC |
| ATEX | II 1G Ex ia IIC T4 Ga | |
| IECEx | Ex ia IIC T4 Ga | |
 |
Conforms to all applicable European directives. | |
|
Conforms to all applicable European directives. For additional certifications, please review the manual or consult Honeywell Analytics. |
||
| Warranty | 2 years | |
Sensor List
| SENSOR | Measuring Range |
|---|---|
| H2S | 0 - 100 ppm |
| CO | 0 - 1,000 ppm |
| O2 | 0 - 25% vol. |
| LEL | 0 - 100% LEL |
※ Caution – the LED IR combustible gas sensor used in Honeywell BW™ Clip4 cannot detect certain combustible gases including hydrogen and acetylene. The application should be reviewed to ensure the Honeywell BW™ Clip4 can provide adequate detection.
